24 strand single mode armored fiber optic cable

Price：Negotiable

24 strand single mode armored fiber optic cable/24f ofc cable

Popular Applications:

1.Data center high-density cabling
2. Intelligent building cabling systems
3. Industrial Ethernet networks in rodent-prone environments
4.G base station indoor equipment interconnects

24-Core Single-Mode Armored Indoor Fiber Optic Cable technical Specifications

Parameter	Specification
Cable Type	24 strand single mode armored fiber optic cable/24f ofc cable
Cable Count	24 Core
Fiber Type	Single-Mode(OS2): 9/125 µm
Fiber Type	Multi-Mode: 50/125 µm or 62.5/125 µm(OM1/OM2/OM3/OM4/OM5)
Cable Diameter	Φ5.0 ± 0.2 mm，6.0 ± 0.25 mm
Jacket Material	Riser/ Plenum
Armor Type	Stainless Steel armor
Tensile Strength	≥ 400 N (Short-Term)
Tensile Strength	≥ 200 N (Long-Term)
Crush Resistance	≥ 3000 N/10 cm
Bending Radius	Dynamic: 20x Cable Diamete
Bending Radius	Static: 10x Cable Diameter
Operating Temperature	-40℃ ~ +70℃
Jacket	UL ,RoHS-Compliant
Attenuation	Single-Mode:1310 nm @ 1550 nm
Attenuation	Multi-Mode: @ 850 nm @ 1300 nm
Bandwidth	Multi-Mode: ≥ 200 MHz·km @ 850
Bandwidth	≥ 500 MHz·km @ 1300 nm
Connector Options	LC, SC, ST, FC, MTP/MPO (Customizable)
Cable Weight	30kg/km

Key Features

1.Good mechanical and environmentai characteristics;
2.soft, flexible, solid, easy to splice ，It’s especially applied to optical long-distance, field, building wiring, trunking connectors;
3.flame retardant characteristics and the meet the requirements of relevant standards;

4.Dual Core Design: Supports both single-mode and multi-mode fiber options.
5.Armored Protection: Enhanced durability with stainless steel armored tube
6.Outer Jacket: Riser/ Plenum
7.High Flexibility: Suitable for dynamic and static installations.
8.Wide Temperature Range: Operates reliably in extreme temperatures.

9.Rodentproof

Fiber Optic Armored Cable Applications:

1.Local Area Networks, including FTTH and FTTD
2.CATV System,Live and music events
3.Telecommunication Networks
4.Industrial Networks: Factory automation, robotics, and harsh environment connectivity.
5.Emergency Repairs: Rapid deployment for disaster recovery and network restoration.
6.Date center
